Clarkson S style collet 3/8″

Description

NOTE; Collets are not actual genuine Clarkson, only 1 x piece per product order. Excellant quality though.

For threaded shank End Mills and Slot Drills
Interchangeable with Clarkson Autolock

Concentricity of outside taper of chuck with respect to bore of chuck within 0.005mm
Case depth maintained within 0.8 to 1.0mm
Concentricity on test mandrel after clamping with threaded collet =0.02mm
Taper matching = 90%

ALSO AVAILABLE ;

INCH AND METRIC SIZES
INCH & METRIC DRAWBARS THREADS

SMALL CHUCK SETS – Inch sets contain chuck and ¼”, 3/8″, ½” & 5/8″ collets and wrench
Metric sets contain chuck & 6mm, 10mm, 12mm & 16mm collets and wrench
Available with MT, ISO, R8 & BT shanks
LARGE CHUCK SETS – Inch sets contain chuck, 1″ & 1 ¼” collets and wrench
Metric sets contain chuck, 25mm & 32mm collets and wrench
Available with MT, ISO, R8 & BT shanks

CENTRES AND LOCKNUTS ARE ALSO AVAILABLE SEPARATELY
COLLETS FOR ENDMILL CHUCKS
for small chucks ¼”, 3/8″, ½”, 5/8″ or 6mm, 10mm, 12mm, 16mm
for large chucks ¾”, 1″, 1 1/4″ or 20mm, 25mm & 32mm
