DORMER A002S3/16 Jobber Drills

Product Code: A002S3/16

$14.39$13.08 Ex. GST

Product Code: A002S3/16 SKU A002S3/16 Categories , ,
DORMER A002S3/16 Jobber Drills
DORMER A002S3/16 Jobber Drills - Image 2
DORMER A002S3/16 Jobber Drills - Image 3
DORMER A002S3/16 Jobber Drills - Image 4

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Jobber length drill with straight shank, diameter 0.1875″ (3/16) with an overall length of 86mm and flute length of 52mm according to DIN 338 standard with 118° modified split point, HSS with TiN-tip coating for 4xD drilling without pecking in steel supplied in 2 piece blister

Additional information

Weight 0.0140 kg
Dimensions Length 8.6cm x Width cm x Depth cm
barcode
Additional Information

Description: Value
EAN number: 7320760673652
Product number (SAP): 86008135
Ordering code ANSI: A002S3/16
Gross weight – grams: 8.69
Cutting diameter – fractional inch (DC): 3/16
Cutting diameter – millimeter (DC): 4.76 mm
Cutting diameter – inch (DC): 0.1875 inch
Length chip flute – millimeter (LCF): 52 mm
Overall length – millimeter (OAL): 86 mm
Connection diameter – millimeter (DCON MS): 4.76 mm
Length chip flute – inch (LCF): 2.0472 inch
ISO: A002S3/16
