DORMER A002S9.5 Jobber Drills

Product Code: A002S9.5

$25.27$22.97 Ex. GST

Product Code: A002S9.5 SKU A002S9.5 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Jobber length drill with straight shank, diameter 9.5mm with an overall length of 125mm and flute length of 81mm according to DIN 338 standard with 118° modified split point, HSS with TiN-tip coating for 4xD drilling without pecking in steel supplied in 1 piece blister

Additional information

Weight 0.0245 kg
Dimensions Length 12.5cm x Width cm x Depth cm
barcode
Additional Information

Description: Value
EAN number: 7320760673829
Product number (SAP): 86008155
Ordering code ANSI: A002S9.5
Gross weight – grams: 52
Cutting diameter – millimeter (DC): 9.5 mm
Cutting diameter – inch (DC): 0.374 inch
Length chip flute – millimeter (LCF): 81 mm
Overall length – millimeter (OAL): 125 mm
Connection diameter – millimeter (DCON MS): 9.5 mm
Length chip flute – inch (LCF): 3.189 inch
ISO: A002S9.5

Brand

DORMER
