DORMER A1006.7 Jobber Drills

Product Code: A1006.7

$12.23$11.12 Ex. GST

Product Code: A1006.7 SKU A1006.7 Categories , ,
DORMER A1006.7 Jobber Drills
DORMER A1006.7 Jobber Drills - Image 2
DORMER A1006.7 Jobber Drills - Image 3
DORMER A1006.7 Jobber Drills - Image 4

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Jobber length drill with straight shank, diameter 6.7mm with an overall length of 101mm and flute length of 63mm according to DIN 338 standard with 118° point angle, HSS with steam tempered finish for 4xD drilling without pecking in steel

Additional information

Weight 0.0119 kg
Dimensions Length 10.1cm x Width cm x Depth cm
barcode
Additional Information

Description: Value
EAN number: 7320760002209
Product number (SAP): 86008542
Ordering code ANSI: A1006.7
Gross weight – grams: 21
Cutting diameter – millimeter (DC): 6.7 mm
Cutting diameter – inch (DC): 0.2638 inch
Length chip flute – millimeter (LCF): 63 mm
Overall length – millimeter (OAL): 101 mm
Connection diameter – millimeter (DCON MS): 6.7 mm
Length chip flute – inch (LCF): 2.4803 inch
ISO: A1006.7

Brand

DORMER
