DORMER A1471/8 HSS-E Jobber Drill

Product Code: A1471/8

$10.88$9.89 Ex. GST

Product Code: A1471/8 SKU A1471/8 Categories , ,
DORMER A1471/8 HSS-E Jobber Drill

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Jobber length drill with straight shank, diameter 0.1250″ (1/8) with an overall length of 65mm and flute length of 36mm according to DIN 338 standard with 130° thinned conical point with corrected cutting lips, cobalt based HSS-E with bright finish for 4xD drilling without pecking in stainless steel

Additional information

Weight 0.0106 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760702420
Product number (SAP): 86031085
Ordering code ANSI: A1471/8
Gross weight – grams: 3.57
Cutting diameter – fractional inch (DC): 1/8
Cutting diameter – millimeter (DC): 3.18 mm
Cutting diameter – inch (DC): 0.125 inch
Length chip flute – millimeter (LCF): 36 mm
Overall length – millimeter (OAL): 65 mm
Connection diameter – millimeter (DCON MS): 3.18 mm
Length chip flute – inch (LCF): 1.4173 inch
ISO: A1471/8

Brand

DORMER
