DORMER E501M16NO3

Description

Straight flute hand tap NO3 with a 2-3xP plug lead, for left hand ISO-Metric thread M16 with 2.00 mm pitch and 6H class of fit, dimensions according to ISO 529 standard with 12.5mm shank and 10.0mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel

Additional information

Weight	0.1716 kg
Dimensions
barcode
Additional Information	Description: Value Product name: E501M16NO3 Product number (SAP): 86016460 EAN number: 7320760095003 Thread diameter size (TDZ): 16 Thread pitch – millimeter (TP): 2 mm Overall length – millimeter (OAL): 102 mm Overall length – inch (OAL): 4.0157 inch Threading length – millimeter (THL): 24 mm Threading length – inch (THL): 0.9449 inch Connection diameter – inch (DCON MS): 0.4921 inch Connection diameter – millimeter (DCON MS): 12.5 mm Flute count (NOF): 4 Tolerance limit: D7 Clamping width – inch (WSC): 0.3937 inch Clamping width – millimeter (WSC): 10 mm Clamping Length – inch (LCS): 0.5118 inch Clamping Length – millimeter (LSC): 13 mm Premachined hole diameter – inch (PHD): 0.5512 inch Premachined hole diameter – millimeter (PHD): 14 mm Gross weight – grams: 97 ISO: E501M16NO3 Ordering code ANSI: E501M16NO3

Need Technical Advice?

Description

Additional information

Brand

DORMER
