DORMER E501M24NO3

Description

Straight flute hand tap NO3 with a 2-3xP plug lead, for left hand ISO-Metric thread M24 with 3.00 mm pitch and 6H class of fit, dimensions according to ISO 529 standard with 18.0mm shank and 14.0mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel

Additional information

Weight	0.3718 kg
Dimensions
barcode
Additional Information	Description: Value Product name: E501M24NO3 Product number (SAP): 86016469 EAN number: 7320760095041 Thread diameter size (TDZ): 24 Thread pitch – millimeter (TP): 3 mm Overall length – millimeter (OAL): 130 mm Overall length – inch (OAL): 5.1181 inch Threading length – millimeter (THL): 35 mm Threading length – inch (THL): 1.378 inch Connection diameter – inch (DCON MS): 0.7087 inch Connection diameter – millimeter (DCON MS): 18 mm Flute count (NOF): 4 Tolerance limit: D8 Clamping width – inch (WSC): 0.5512 inch Clamping width – millimeter (WSC): 14 mm Clamping Length – inch (LCS): 0.7087 inch Clamping Length – millimeter (LSC): 18 mm Premachined hole diameter – inch (PHD): 0.8268 inch Premachined hole diameter – millimeter (PHD): 21 mm Gross weight – grams: 260 ISO: E501M24NO3 Ordering code ANSI: E501M24NO3

Need Technical Advice?

Description

Additional information

Brand

DORMER
