DORMER E5243/4NO6 HSS Straight Flute Taps

Description

Set of straight flute hand taps NO6 for Unified National Fine thread UNF 3/4″ with 16 TPI and 2B class of fit, consisting of 1 tap with a 6-8xP taper lead, 1 tap with a 4-6xP second lead and 1 tap with a 2-3xP plug lead, dimensions according to ISO 529 standard with 14.0mm shank and 11.2mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel and copper or copper alloys

Additional information

Weight	0.4059 kg
Dimensions
barcode
Additional Information	Description: Value Product name: E5243/4NO6 Product number (SAP): 86016857 EAN number: 7320760153352 Thread diameter size (TDZ): 3/4 Thread diameter – millimeter (TD): 19.05 mm Threads per inch (TPI): 16 Overall length – millimeter (OAL): 112 mm Overall length – inch (OAL): 4.4094 inch Threading length – millimeter (THL): 29 mm Threading length – inch (THL): 1.1417 inch Connection diameter – inch (DCON MS): 0.5512 inch Connection diameter – millimeter (DCON MS): 14 mm Flute count (NOF): 4 Clamping width – inch (WSC): 0.4409 inch Clamping width – millimeter (WSC): 11.2 mm Clamping Length – inch (LCS): 0.5512 inch Clamping Length – millimeter (LSC): 14 mm Premachined hole diameter – inch (PHD): 0.689 inch Premachined hole diameter – millimeter (PHD): 17.5 mm Gross weight – grams: 457.4 ISO: E5243/4NO6 Ordering code ANSI: E5243/4NO6
