Home » Shop » CUTTING TOOLS (HSS & Carbide) » Threading » DORMER E559M8X1.0NO9 Professional HSS Taps
$35.57$32.34 Ex. GST
Thread size MF8 mm x 1 mm, with thread tolerance class 93707.
3603607151471
Description: Value Product name: E559M8X1.0NO9 Thread diameter size (TDZ): 8 Thread pitch – millimeter (TP): 1 mm Overall length – millimeter (OAL): 69 mm Thread diameter – millimeter (TD): 8 mm Threading length – millimeter (THL): 19 mm Connection diameter – millimeter (DCON MS): 8 mm Clamping width – millimeter (WSC): 6.3 mm Clamping Length – millimeter (LSC): 9 mm Flute count (NOF): 3 Premachined hole diameter – millimeter (PHD): 7 mm Usable Length – millimeter (LU): 32 mm
