DORMER G70521/32 Countersinks / Bors

Description: Value
EAN number: 3603607032589
Product number (SAP): 86041084
Ordering code ANSI: G70521/32
Product name: G70521/32
Gross weight – grams: 122.4
Body diameter – fractional inch (BD): 9/16
Body diameter – millimeter (BD): 14.29 mm
Connection diameter – fractional inch (DCON MS): 1/2
Connection diameter – millimeter (DCON MS): 12.7 mm
Cutting diameter – fractional inch (DC): 21/32
Cutting diameter – inch (DC): 0.6563 inch
Cutting diameter – millimeter (DC): 16.67 mm
Guide Pilot Diameter – fractional inch (GPD): 3/16
Guide Pilot Diameter maximum – fractional inch (GPDX): 5/8
Minimal Guide Pilot Diameter – fractional inch (GPDN): 3/16
Flute count (NOF): 4
Overall length – fractional inch (OAL): 5.3/8
Overall length – millimeter (OAL): 136.53 mm
Shank length – fractional inch (LS): 9/16
Usable Length – fractional inch (LU): 5/8
Usable Length – inch (LU): 0.625 inch
ISO: G70521/32
Connection bore diameter – fractional inch (DCB): 3/16
Functional length – fractional inch (LF): 1.1/4
