DORMER S1473/16 Carbide Cutters

Product Code: S1473/16

$75.35$68.50 Ex. GST

Product Code: S1473/16 SKU S1473/16 Categories , ,
DORMER S1473/16 Carbide Cutters

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Extra long series ball-nose end mill with 4 flutes, diameter 3/16″ with 1.1/8″ length of cut, 3″ overall length and 3/32″ full profile radius, according to DORMER standard with a 3/16″ plain shank, solid carbide with bright finish, 30° helix for copy milling in steel and cast steel, stainless steel, malleable, ductile and compacted graphite cast-iron and copper or copper alloys

Additional information

Weight 0.0732 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760849422
Product number (SAP): 86036185
Ordering code ANSI: S1473/16
Gross weight – grams: 19
Connection diameter – fractional inch (DCON MS): 3/16
Connection diameter – millimeter (DCON MS): 4.76 mm
Cutting diameter – fractional inch (DC): 3/16
Cutting diameter – millimeter (DC): 4.76 mm
Depth of cut maximum – fractional inch (APMX): 1.1/8
Overall length – fractional inch (OAL): 3"
Overall length – millimeter (OAL): 76.2 mm
ISO: S1473/16

Brand

DORMER
