DORMER S1475/8 Carbide Cutters

Product Code: S1475/8

$371.62$337.84 Ex. GST

Product Code: S1475/8 SKU S1475/8 Categories , ,
DORMER S1475/8 Carbide Cutters

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Extra long series ball-nose end mill with 4 flutes, diameter 5/8″ with 3″ length of cut, 6″ overall length and 5/16″ full profile radius, according to DORMER standard with a 5/8″ plain shank, solid carbide with bright finish, 30° helix for copy milling in steel and cast steel, stainless steel, malleable, ductile and compacted graphite cast-iron and copper or copper alloys

Additional information

Weight 0.3608 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760849477
Product number (SAP): 86036190
Ordering code ANSI: S1475/8
Gross weight – grams: 364
Connection diameter – fractional inch (DCON MS): 5/8
Connection diameter – millimeter (DCON MS): 15.88 mm
Cutting diameter – fractional inch (DC): 5/8
Cutting diameter – millimeter (DC): 15.88 mm
Depth of cut maximum – fractional inch (APMX): 3"
Overall length – fractional inch (OAL): 6"
Overall length – millimeter (OAL): 152.4 mm
ISO: S1475/8

Brand

DORMER
