DORMER S2268.0 Carbide Cutters

Product Code: S2268.0

$173.35$157.59 Ex. GST

Product Code: S2268.0 SKU S2268.0 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Long series finishing end mill with 6 flutes, diameter 8mm with 31mm length of cut, 75mm overall length and 40mm reach with neck relief, according to DORMER standard with a 8mm plain shank, solid carbide with AlTiN coating, 50° helix and 3° rake angle for shoulder milling in martensitic, austenitic and super-austenitic, Duplex or precipitation hardening stainless steel and high-temperature alloys

Additional information

Weight 0.1683 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760683323
Product number (SAP): 86021920
Ordering code ANSI: S2268.0
Gross weight – grams: 52.9
Cutting diameter – millimeter (DC): 8 mm
Connection diameter – millimeter (DCON MS): 8 mm
Depth of cut maximum – millimeter (APMX): 31 mm
Overall length – millimeter (OAL): 75 mm
Flute count (NOF): 6
Usable Length – millimeter (LU): 40 mm
Neck diameter – millimeter (DN): 7.4 mm
Radial rake angle (GAMF): 3
With Neck: Yes
ISO: S2268.0

Brand

DORMER
