DORMER S2385/8 Carbide Cutters

Product Code: S2385/8

$294.58$267.80 Ex. GST

Product Code: S2385/8 SKU S2385/8 Categories , ,
DORMER S2385/8 Carbide Cutters

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au
Get advice now

Description

Regular length ball-nose end mill with 4 flutes, diameter 5/8″ with 1.1/4″ length of cut, 3.1/2″ overall length and 5/16″ full profile radius, according to DORMER standard with a 5/8″ plain shank, solid carbide with TiAlN coating, 30° helix for copy milling in steel and cast steel, stainless steel and cast-iron

Additional information

Weight 0.286 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760849149
Product number (SAP): 86036157
Ordering code ANSI: S2385/8
Gross weight – grams: 160
Connection diameter – fractional inch (DCON MS): 5/8
Connection diameter – millimeter (DCON MS): 15.88 mm
Cutting diameter – fractional inch (DC): 5/8
Cutting diameter – millimeter (DC): 15.88 mm
Depth of cut maximum – fractional inch (APMX): 1.1/4
Overall length – fractional inch (OAL): 3.1/2
Overall length – millimeter (OAL): 88.9 mm
ISO: S2385/8

Brand

DORMER
