DORMER S2393.0 Carbide Cutters

Product Code: S2393.0

$39.77$36.15 Ex. GST

Product Code: S2393.0 SKU S2393.0 Categories 10 - SC Cutters, CUTTING TOOLS (HSS & Carbide), Milling

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Regular length ball-nose end mill with 4 flutes, diameter 3mm with 12mm length of cut, 38mm overall length and 1.5mm full profile radius, according to DORMER standard with a 3mm plain shank, solid carbide with TiAlN coating, 30° helix for copy milling in steel and cast steel, stainless steel and cast-iron

Additional information

Weight	0.0386 kg
Dimensions
barcode
Additional Information	Description: Value EAN number: 7320760849262 Product number (SAP): 86036169 Ordering code ANSI: S2393.0 Gross weight – grams: 6 Connection diameter – millimeter (DCON MS): 3 mm Cutting diameter – millimeter (DC): 3 mm Depth of cut maximum – millimeter (APMX): 12 mm Overall length – millimeter (OAL): 38 mm ISO: S2393.0
