DORMER S722HB8.0 Carbide Cutters

Product Code: S722HB8.0

$157.49$143.17 Ex. GST

Product Code: S722HB8.0 SKU S722HB8.0 Categories , ,

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Regular length End mill with 4 flutes, diameter 8mm with 20mm length of cut, 64mm overall length, 26mm reach with neck relief and 0.2mm corner radii, according to DORMER standard with a 8mm Weldon shank, solid carbide with AlCrN coating, 40° helix and 7° rake angle for shoulder milling in steel and cast steel, stainless steel, cast-iron or high-temperature alloys

Additional information

Weight 0.1529 kg
Dimensions
barcode
Additional Information

Description: Value
EAN number: 7320760950753
Product number (SAP): 86038180
Ordering code ANSI: S722HB8.0
Gross weight – grams: 45.3
Cutting diameter – millimeter (DC): 8 mm
Corner radius – millimeter (RE): 0.2 mm
Connection diameter – millimeter (DCON MS): 8 mm
Depth of cut maximum – millimeter (APMX): 20 mm
Overall length – millimeter (OAL): 64 mm
Flute count (NOF): 4
Usable Length – millimeter (LU): 26 mm
Neck diameter – millimeter (DN): 7.4 mm
Radial rake angle (GAMF): 7
With Neck: Yes
ISO: S722HB8.0

Brand

DORMER
