DORMER T210M12 Thread Milling Cutters

Description: Value
Product name: T210M12
Product number (SAP): 86031180
EAN number: 7320760706565
Thread diameter size (TDZ): 12
Thread pitch – millimeter (TP): 1.75 mm
Overall length – millimeter (OAL): 110 mm
Overall length – inch (OAL): 4.3307 inch
Threading length – millimeter (THL): 32 mm
Threading length – inch (THL): 1.2598 inch
Connection diameter – inch (DCON MS): 0.4724 inch
Connection diameter – millimeter (DCON MS): 12 mm
Flute count (NOF): 6
Clamping width – inch (WSC): 0.3543 inch
Clamping width – millimeter (WSC): 9 mm
Clamping Length – inch (LCS): 0.4724 inch
Clamping Length – millimeter (LSC): 12 mm
Premachined hole diameter – inch (PHD): 0.4094 inch
Premachined hole diameter – millimeter (PHD): 10.4 mm
Gross weight – grams: 159
ISO: T210M12
Ordering code ANSI: T210M12
