Guhring 9/16-12 UNC 2B PM HSS-E Gun Nose Tap TiN Coated Red Ring

Product Code: 3992 14,288

$338.84$308.04 Ex. GST

Product Code: 3992 14,288 SKU 3992 14,288 Category CUTTING TOOLS (HSS & Carbide)

Guhring 9/16-12 UNC 2B PM HSS-E Gun Nose Tap TiN Coated Red Ring

Guhring 9/16-12 UNC 2B PM HSS-E Gun Nose Tap TiN Coated Red Ring - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Machine taps for UNC-threads 9/16 – 12 / 2B / Company std. / DIN/ANSI / HSS-E-PM / TiN / Type: H / Form: B / through hole / Cutting direction: right-hand

Additional information

Weight	0.0500 kg
Dimensions
barcode
Additional Information	Connection Code Machine Side: Straight Shank Internal Cooling: Without Norm: Company Std. Surface: TiN Discount Group: 103 Type: 3992 Cutting Direction: Right-hand Type: H Material: HSS-E-PM Additional Information: Internal Threading Form: B Coloured Ring: Red Ring Threads: UNC Tolerance Class Thread: 2B Hole Type: Through Hole Groove: Straight-fluted Cutting Edges Chamfer Lead Length: 3.5-5.5 Code No.: 14.288 Weight: 0.050 No of Cutting Edges: 4 Total Length: 110.000 Thread Length: 28.000 Groove Length: 49.000 Usable Length: 53.000 Norm 2: DIN/ANSI Wrench Opening 1: 8.180 Core Hole Ø: 12.20 Shank Ø: 10.897 Nominal Dimension Thread: 9/16 – 12 External Ø: 14.380 Pitch Thread/Inch: 12.000 Reach Length: 58.000 Statistical Goods Number: 82074010

Brand

Guhring
