Guhring BSP Gun Tap HSS-E Blue Bland Sirius Coated G 1/4

Description

Machine taps f. BSP-threads G1/4 / 3xD / DIN 5156 / DIN 2184-1 / HSS-E / Sirius / Type: VA / Form: B / through hole / Cutting direction: right-hand

Weight	0.075 kg
Dimensions
barcode
Additional Information	Connection code machine side: straight shank Internal cooling: without Norm: DIN 5156 Surface: Sirius Discount group: 103 Type: 4220 Cutting direction: right-hand Type: VA Material: HSS-E Additional information: Internal threading Form: B Coloured ring: blue ring Threads: BSP Hole type: through hole Groove: straight-fluted cutting edges Chamfer lead length: 3.5-5.5 Code no.: 13.157 Weight: 0.075 No of cutting edges: 4 Total length: 100.000 Thread length: 20.000 Groove length: 36.000 Usable length: 40.000 Norm 2: DIN 2184-1 Wrench opening 1: 9.000 Neck Ø: 10.800 Core hole Ø: 11.80 Shank Ø: 11.000 Nominal dimension thread: G1/4 Pitch: 1.337 External Ø: 13.240 Shank length: 59.900 Pitch thread/inch: 19.000 Reach length: 45.000 Statistical goods number: 82074010
