Guhring Carbide Ratio Endmill 4-fl Fire Coated Long Series

Connection code machine side: DIN 6535-HA
Nominal Ø tolerance field: h10
Internal cooling: without
Norm: Company std.
Surface: FIRE
Discount group: 157
Type: 5582
Cutting direction: right-hand
Type: N
Material: Solid carbide
No of cutting edges: 4
(Variety): ≤ 48
Helix angle: 35/38
Code no.: 12.000
Weight: 0.213
Total length: 150.000
Groove length: 53.040
Usable length: 58.000
Neck Ø: 11.500
Shank Ø: 12.000
Nominal Ø mm: 12.000
Cutting edge length: 45.000
Reach length: 105.000
Corner chamfer: 0.200
Statistical goods number: 82077010
