Guhring Carbide Ratio Endmill 4-fl For Stainless Fire Coated

Description

Ratio end mills RF 100 VA / Ø 8.000 mm / h10 / DIN 6527L / Solid carbide / TiAlN-nanoA / Type: N / Form: B / Cutting direction: right-hand

Weight	0.041 kg
Dimensions
barcode	9056540080000
Additional Information	Connection code machine side: DIN 6535-HB Nominal Ø tolerance field: h10 Internal cooling: without Norm: DIN 6527L Surface: TiAlN-nanoA Discount group: 157 Type: 5654 Cutting direction: right-hand Type: N Material: Solid carbide Identification (Article No.): New No of cutting edges: 4 Form: B Helix angle: 36/38 Code no.: 8.000 Weight: 0.041 Total length: 63.000 Groove length: 24.600 Usable length: 26.000 Neck Ø: 7.700 Shank Ø: 8.000 Nominal Ø mm: 8.000 Cutting edge length: 19.000 Reach length: 27.000 Corner chamfer: 0.250 Statistical goods number: 82077010
