Guhring Metric Fine M12 x 1.5 Spiral Flute Tap HSS-e Blue Band For Blind holes Made in Germany

Connection code machine side: Straight shank
Internal cooling: Without
Norm: DIN 374
Surface: Steam tempered
Discount group: 103
Type: 2864
Cutting direction: Right-hand
Type: VA R40
Material: HSS-E
Additional information: Internal threading
Form: C
Coloured ring: Blue ring
Threads: MF
Tolerance class thread: ISO2/6H
Hole type: Blind hole
Groove: 40° right-hand helix
Chamfer lead length: 2-3
Code no.: 12.007
Weight: 0.053
No of cutting edges: 3
Total length: 100.000
Thread length: 15.000
Groove length: 36.000
Usable length: 40.000
Norm 2: DIN 2184-1
Wrench opening 1: 7.000
Neck Ø: 8.800
Core hole Ø: 10.50
Shank Ø: 9.000
Nominal dimension thread: M12 x 1.5
Pitch: 1.500
External Ø: 12.080
Reach length: 46.000
Statistical goods number: 82074010
