Guhring Gun Nose Tap PM HSS-E TiN Coat Red/Blue Band

Connection code machine side: straight shank
Internal cooling: without
Norm: DIN 376
Surface: TiN
Discount group: 103
Type: 58
Cutting direction: right-hand
Type: H
Material: HSS-E-PM
Additional information: Internal threading
Form: B
Coloured ring: red ring
Threads: M
Tolerance class thread: ISO2/6H
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 14.000
Weight: 0.096
No. of cutting edges: 4
Total length: 110.000
Thread length: 26.000
Groove length: 49.000
Usable length: 53.000
Norm 2: DIN 2184-1
Wrench opening 1: 9.000
Neck Ø: 10.800
Core hole Ø: 12.00
Shank Ø: 11.000
Nominal dimension thread: M14
Pitch: 2.000
External Ø: 14.090
Reach length: 58.000
Statistical goods number: 82074010
