Guhring Jobber drill Solid Carbide

Product Code: 5517 4,000

$65.54$59.58 Ex. GST

Product Code: 5517 4,000 SKU 5517 4,000 Category

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Twist drills short Solid carbide / Ø 4.000 mm h7 / Company std. / Surface: bright / Cutting direction: right-hand / facet point grinding 118°
Execution: Web thinning ≥ Ø 3.000 mm • facet point grind • main cutting edge form straight
Application: structural and case hardened steels • free-cutting steels, heat-treatable steels • grey cast iron • bronze, brass • aluminium and Al alloys • magnesium and magnesium alloys • plastics and fiber reinforced plastics

Additional information

Weight 0.0100 kg
Dimensions
barcode
Additional Information

Point grinding: Facet point grinding
Connection code machine side: Straight shank
Ø-Thinning: 3
Nominal Ø tolerance field: h7
Internal cooling: Without
Norm: Company std.
Surface: Bright
Discount group: 155
Type: 5517
Cutting direction: Right-hand
Type: N
Point angle: 118
Material: Solid carbide
Code no.: 4
Weight: 0.01
No of cutting edges: 2
Total length: 75
Groove length: 43
Usable length: 38
Shank Ø: 4
Shank length: 32
Nominal Ø mm: 4
Statistical goods number: 82075050

Brand

Guhring
