Guhring M 18 x 2.5 Bottoming Hand Tap HSS

Product Code: 864 18,000

$177.01$160.92 Ex. GST

Product Code: 864 18,000 SKU 864 18,000 Category CUTTING TOOLS (HSS & Carbide)

Guhring M 18 x 2.5 Bottoming Hand Tap HSS

Guhring M 18 x 2.5 Bottoming Hand Tap HSS - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Bottoming tap Hand taps for ISO metric threads M18 / ISO2/6H / DIN 352 / DIN 2184-2 / HSS / bright / Type: N / Form: C / through-, blind hole / Cutting direction: right-hand /
Application: P ≤ 800 N/mm²

Additional information

Weight	0.1030 kg
Dimensions
barcode
Additional Information	Connection code machine side: straight shank Internal cooling: without Norm: DIN 352 Surface: bright Discount group: 118 Type: 864 Cutting direction: right-hand Type: N Material: HSS Additional information: Bottoming tap Form: C Threads: M Tolerance class thread: ISO2/6H Hole type: through-, blind hole Groove: straight-fluted cutting edges Chamfer lead length: 2-3 Code no.: 18.000 Weight: 0.103 No of cutting edges: 4 Total length: 95.000 Thread length: 30.000 Groove length: 46.000 Norm 2: DIN 2184-2 Wrench opening 1: 11.000 Neck Ø: 13.800 Core hole Ø: 15.50 Shank Ø: 14.000 Nominal dimension thread: M18 Pitch: 2.500 External Ø: 18.100 Statistical goods number: 82074010

Brand

Guhring
