Guhring Metric Gun Nose Taps HSS-E 6HX SIRIUS Coated

Connection code machine side: straight shank
Internal cooling: without
Norm: DIN 371
Surface: Sirius
Discount group: 103
Type: 4218
Cutting direction: right-hand
Type: VA
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: blue ring
Threads: M
Tolerance class thread: 6HX
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 2.500
Weight: 0.022
No of cutting edges: 3
Total length: 50.000
Thread length: 9.000
Groove length: 12.500
Usable length: 14.500
Norm 2: DIN 2184-1
Wrench opening 1: 2.100
Neck Ø: 2.000
Core hole Ø: 2.05
Shank Ø: 2.800
Nominal dimension thread: M2.5
Pitch: 0.450
External Ø: 2.540
Shank length: 32.700
Reach length: 31.000
Statistical goods number: 82074010
