Guhring Metric Spiral Long Series Tap-TiN Coated HSS-E Gold Band

Description

Machine taps for ISO metric threads M6 / 6HX / Company std. / HSS-E / TiN / Type: N R40 / Form: C / blind hole / Cutting direction: right-hand

Weight	0.0210 kg
Dimensions
barcode
Additional Information	Connection code machine side: Straight shank Internal cooling: Without Norm: Company std. Surface: TiN Discount group: 203 Type: 5718 Cutting direction: Right-hand Type (N R40): N R40 Material: HSS-E Additional information: Internal threading Form: C Coloured ring: Gold ring Threads: M Tolerance class thread: 6HX Hole type: Blind hole Groove: 40° right-hand helix Chamfer lead length: 2-3 Code no.: 6.000 Weight: 0.021 No of cutting edges: 3 Total length: 125.000 Thread length: 11.000 Groove length: 26.000 Usable length: 85.000 Wrench opening 1: 3.400 Neck Ø: 4.300 Core hole Ø: 5.00 Shank Ø: 4.500 Nominal dimension thread: M6 Pitch: 1.000 External Ø: 6.060 Reach length: 104.000 Statistical goods number: 82074010
