Guhring Metric Spiral Tap HSS-E Blue band TiAlN coated 6HX

Connection Code Machine Side: straight shank
Internal Cooling: without
Norm: DIN 371
Surface: TiAlN
Discount Group: 103
Type: 393
Cutting Direction: right-hand
Type: VA R45
Material: HSS-E
Additional Information: Internal threading
Form: C
Coloured Ring: blue ring
Threads: M
Tolerance Class Thread: 6HX
Hole Type: blind hole
Groove: 45° right hand helix
Chamfer Lead Length: 2-3
Code No.: 8.000
Weight: 0.032
No. of Cutting Edges: 3
Total Length: 90.000
Thread Length: 14.000
Groove Length: 31.000
Usable Length: 35.000
Norm 2: DIN 2184-1
Wrench Opening 1: 6.200
Neck Ø: 6.300
Core Hole Ø: 6.80
Shank Ø: 8.000
Nominal Dimension Thread: M8
Pitch: 1.250
External Ø: 8.070
Reach Length: 68.000
Statistical Goods Number: 82074010
