Guhring Metric Spiral Tap-TiN Coated HSS-E-PM Gold Band

Connection code machine side: Straight shank
Internal cooling: Without
Norm: DIN 376
Surface: TiN
Discount group: 203
Type: 5722
Cutting direction: Right-hand
Type (N R50): N R50
Material: HSS-E-PM
Additional information: Internal threading
Form: C
Coloured ring: Gold ring
Threads: M
Tolerance class thread: ISO2/6H
Hole type: Blind hole
Groove: 50° right-hand helix
Chamfer lead length: 2-3
Code no.: 16.000
Weight: 0.089
No of cutting edges: 4
Total length: 110.000
Thread length: 20.000
Groove length: 50.000
Usable length: 54.000
Norm 2: DIN 2184-1
Wrench opening 1: 9.000
Neck Ø: 11.800
Core hole Ø: 14.00
Shank Ø: 12.000
Nominal dimension thread: M16
Pitch: 2.000
External Ø: 16.090
Reach length: 59.000
Statistical goods number: 82074010
