Guhring No. 12-24 UNC Spiral Taps HSS-E Yellow band

Connection code machine side: straight shank
Internal cooling: without
Norm: ~DIN 371
Surface: bright
Discount group: 103
Type: 876
Cutting direction: right-hand
Type: N R40
Material: HSS-E
Additional information: Internal threading
Form: C
Coloured ring: yellow ring
Threads: UNC
Tolerance class thread: 2B
Hole type: blind hole
Groove: 40° right hand helix
Chamfer lead length: 2-3
Code no.: 5.486
Weight: 0.016
No of cutting edges: 3
Total length: 80.000
Thread length: 11.000
Groove length: 26.000
Usable length: 30.000
Norm 2: DIN 2184-1
Wrench opening 1: 4.900
Neck Ø: 4.400
Core hole Ø: 4.50
Shank Ø: 6.000
Nominal dimension thread: 12 – 24
Pitch: 1.058
External Ø: 5.560
Pitch thread/inch: 24.000
Reach length: 60.000
Statistical goods number: 82074010
