Guhring PM HSS-E FLUTELESS TAPS 1/2 -20 UNF TiCN-COATED

Product Code: 4492 12,700

$293.54$266.85 Ex. GST

Product Code: 4492 12,700 SKU 4492 12,700 Category CUTTING TOOLS (HSS & Carbide)

Guhring PM HSS-E FLUTELESS TAPS 1/2 -20 UNF TiCN-COATED

Guhring PM HSS-E FLUTELESS TAPS 1/2 -20 UNF TiCN-COATED - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Fluteless machine taps for UNF-threads 1/2 – 20 / 2BX / 3xD / ~DIN 374 / DIN 2184-1 / HSS-E-PM / TiCN / Type: N / Form: C / through-, blind hole / Cutting direction: right-hand /
Application: N ≥ 7% Si

Additional information

Weight	0.0620 kg
Dimensions
barcode
Additional Information	Connection code machine side: Straight shank Internal cooling: Without Norm: ~DIN 374 Surface: TiCN Discount group: 208 Type: 4492 Cutting direction: Right-hand Type: N Material: HSS-E-PM Additional information: Internal threading Form: C Threads: UNF Tolerance class thread: 2BX Hole type: Through, Blind hole Groove: With oil grooves Chamfer lead length: 2-3 Code no.: 12.700 Weight: 0.062 Number of cutting edges: 7 Total length: 100.000 Thread length: 20.000 Groove length: 31.000 Usable length: 40.000 Norm 2: DIN 2184-1 Wrench opening: 7.000 Neck Ø: 8.800 Core hole Ø: 12.10 Shank Ø: 9.000 Nominal dimension thread: 1/2 – 20 External Ø: 12.790 Pitch thread/inch: 20.000 Reach length: 46.000 Body Ø: 9.000 Statistical goods number: 82074010

Brand

Guhring
