Guhring PM HSS-E FLUTELESS TAPS 3/8 -16 UNC TiCN-COATED

Connection code machine side: Straight shank
Internal cooling: Without
Norm: ~DIN 371
Surface: TiCN
Discount group: 208
Type: 4491
Cutting direction: Right-hand
Type: N
Material: HSS-E-PM
Additional information: Internal threading
Form: C
Threads: UNC
Tolerance class thread: 2BX
Hole type: Through, Blind hole
Groove: With oil grooves
Chamfer lead length: 2-3
Code no.: 9.525
Weight: 0.056
Number of cutting edges: 5
Total length: 100.000
Thread length: 20.000
Groove length: 31.000
Usable length: 39.000
Norm 2: DIN 2184-1
Wrench opening: 8.000
Neck Ø: 7.600
Core hole Ø: 8.80
Shank Ø: 10.000
Nominal dimension thread: 3/8 – 16
External Ø: 9.610
Pitch thread/inch: 16.000
Reach length: 78.000
Body Ø: 10.000
Statistical goods number: 82074010
