Guhring Ratio End Mill RF100 VA – IC 36°/38° NANO-A COATED For Stainless Steel

Connection code machine side: DIN 6535-HA
Nominal Ø tolerance field: h10
Internal cooling: with
Norm: DIN 6527L
Surface: TiAlN-nanoA
Discount group: 106
Type: 6700
Cutting direction: right-hand
Type: N
Material: Solid carbide
No of cutting edges: 4
Form: A
Helix angle: 36/38
Code no.: 6.000
Weight: 0.021
Total length: 57.000
Groove length: 17.200
Usable length: 20.000
Neck Ø: 5.700
Shank Ø: 6.000
Nominal Ø mm: 6.000
Cutting edge length: 13.000
Reach length: 21.000
Corner chamfer: 0.200
Statistical goods number: 82077010
