Guhring UNC Gun Taps HSS-E Gold Band 3/8 -16

Connection code machine side: Straight shank
Internal cooling: Without
Norm: DIN 371
Surface: Steam tempered
Discount group: 203
Type: 5725
Cutting direction: Right-hand
Type (N): N
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: Gold ring
Threads: UNC
Tolerance class thread: 2B
Hole type: Through hole
Groove: Straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 9.525
Weight: 0.053
No of cutting edges: 3
Total length: 100.000
Thread length: 20.000
Groove length: 35.000
Usable length: 39.000
Norm 2: DIN 2184-1
Wrench opening 1: 8.000
Neck Ø: 7.600
Core hole Ø: 8.00
Shank Ø: 10.000
Nominal dimension thread: 3/8 – 16
Pitch: 1.587
External Ø: 9.610
Pitch thread/inch: 16.000
Reach length: 78.000
Statistical goods number: 82074010
