Guhring UNC Gun Taps HSS-E Gold Band 7/16-14

Product Code: 5725 11,113

$107.00$97.27 Ex. GST

Product Code: 5725 11,113 SKU 5725 11,113 Category CUTTING TOOLS (HSS & Carbide)

Guhring UNC Gun Taps HSS-E Gold Band 7/16-14

Guhring UNC Gun Taps HSS-E Gold Band 7/16-14 - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Machine taps for UNC-threads 7/16 – 14 / 2B / ~DIN 376 / DIN 2184-1 / HSS-E / steam tempered / Type: N / Form: B / through hole / Cutting direction: right-hand

Additional information

Weight	0.0460 kg
Dimensions
barcode
Additional Information	Connection code machine side: Straight shank Internal cooling: Without Norm: DIN 376 Surface: Steam tempered Discount group: 203 Type: 5725 Cutting direction: Right-hand Type (N): N Material: HSS-E Additional information: Internal threading Form: B Coloured ring: Gold ring Threads: UNC Tolerance class thread: 2B Hole type: Through hole Groove: Straight-fluted cutting edges Chamfer lead length: 3.5-5.5 Code no.: 11.113 Weight: 0.046 No of cutting edges: 3 Total length: 100.000 Thread length: 22.000 Groove length: 38.000 Usable length: 42.000 Norm 2: DIN 2184-1 Wrench opening 1: 6.200 Neck Ø: 7.800 Core hole Ø: 9.40 Shank Ø: 8.000 Nominal dimension thread: 7/16 – 14 Pitch: 1.814 External Ø: 11.200 Pitch thread/inch: 14.000 Reach length: 47.000 Statistical goods number: 82074010

Brand

Guhring
