Guhring UNC Gun Taps HSS-E Gold Band NR. 8 -32

Connection code machine side: Straight shank
Internal cooling: Without
Norm: DIN 371
Surface: Steam tempered
Discount group: 203
Type: 5725
Cutting direction: Right-hand
Type (N): N
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: Gold ring
Threads: UNC
Tolerance class thread: 2B
Hole type: Through hole
Groove: Straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 4.166
Weight: 0.008
No of cutting edges: 3
Total length: 63.000
Thread length: 12.000
Groove length: 17.000
Usable length: 21.000
Norm 2: DIN 2184-1
Wrench opening 1: 3.400
Neck Ø: 3.200
Core hole Ø: 3.50
Shank Ø: 4.500
Nominal dimension thread: 8 – 32
Pitch: 0.794
External Ø: 4.220
Pitch thread/inch: 32.000
Reach length: 43.000
Statistical goods number: 82074010
