Guhring UNF Gun Taps HSS-E Blue band Sirius coated No 12-28

Connection code machine side: straight shank
Internal cooling: without
Norm: ~DIN 371
Surface: Sirius
Discount group: 103
Type: 4643
Cutting direction: right-hand
Type: VA
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: blue ring
Threads: UNF
Tolerance class thread: 2BX
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 5.486
Weight: 0.168
No of cutting edges: 3
Total length: 80.000
Thread length: 16.000
Groove length: 26.000
Usable length: 30.000
Norm 2: DIN 2184-1
Wrench opening 1: 4.900
Neck Ø: 4.400
Core hole Ø: 4.60
Shank Ø: 6.000
Nominal dimension thread: 12 – 28
External Ø: 5.550
Pitch thread/inch: 28.000
Reach length: 60.000
Statistical goods number: 82074010
