Guhring UNF Gun Taps HSS-E Blue band Sirius coated No 8-36

Connection code machine side: straight shank
Internal cooling: without
Norm: ~DIN 371
Surface: Sirius
Discount group: 103
Type: 4643
Cutting direction: right-hand
Type: VA
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: blue ring
Threads: UNF
Tolerance class thread: 2BX
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 4.166
Weight: 0.009
No of cutting edges: 3
Total length: 63.000
Thread length: 12.000
Groove length: 17.000
Usable length: 21.000
Norm 2: DIN 2184-1
Wrench opening 1: 3.400
Neck Ø: 3.200
Core hole Ø: 3.50
Shank Ø: 4.500
Nominal dimension thread: 8 – 36
External Ø: 4.210
Pitch thread/inch: 36.000
Reach length: 43.000
Statistical goods number: 82074010
