Guhring UNF Gun Taps HSS-E Gold Band 5/8 -18

Connection code machine side: straight shank
Internal cooling: without
Norm: ~DIN 374
Surface: steam tempered
Discount group: 203
Type: 5727, N
Cutting direction: right-hand
Material: HSS-E
Additional information: Internal threading
Form: B
Coloured ring: gold ring
Threads: UNF
Tolerance class thread: 2B
Hole type: through hole
Groove: straight-fluted cutting edges
Chamfer lead length: 3.5-5.5
Code no.: 15.875
Weight: 0.091
No of cutting edges: 4
Total length: 100.000
Thread length: 22.000
Groove length: 40.000
Usable length: 44.000
Norm 2: DIN 2184-1
Wrench opening 1: 9.000
Neck Ø: 11.800
Core hole Ø: 14.50
Shank Ø: 12.000
Nominal dimension thread: 5/8 – 18
Pitch: 1.411
External Ø: 15.970
Pitch thread/inch: 18.000
Reach length: 49.000
Statistical goods number: 82074010
