Guhring UNF Spiral Taps HSS-E Blue Band TiAlN Coated 1/2

Connection Code Machine Side: straight shank
Internal Cooling: without
Norm: ~DIN 374
Surface: TiAlN
Discount Group: 103
Type: 392
Cutting Direction: right-hand
Type: VA R45
Material: HSS-E
Additional Information: Internal threading
Form: C
Coloured Ring: blue ring
Threads: UNF
Tolerance Class Thread: 2BX
Hole Type: blind hole
Groove: 45° right hand helix
Chamfer Lead Length: 2-3
Code No.: 12.700
Weight: 0.054
No. of Cutting Edges: 3
Total Length: 100.000
Thread Length: 13.000
Groove Length: 36.000
Usable Length: 40.000
Norm 2: DIN 2184-1
Wrench Opening 1: 7.000
Neck Ø: 8.800
Core Hole Ø: 11.50
Shank Ø: 9.000
Nominal Dimension Thread: 1/2 – 20
External Ø: 12.790
Pitch Thread/Inch: 20.000
Reach Length: 46.000
Statistical Goods Number: 82074010
