Guhring UNF Spiral Taps HSS-E Blue Band TiAlN Coated No 10-32

Connection Code Machine Side: straight shank
Internal Cooling: without
Norm: ~DIN 371
Surface: TiAlN
Discount Group: 103
Type: 392
Cutting Direction: right-hand
Type: VA R45
Material: HSS-E
Additional Information: Internal threading
Form: C
Coloured Ring: blue ring
Threads: UNF
Tolerance Class Thread: 2BX
Hole Type: blind hole
Groove: 45° right hand helix
Chamfer Lead Length: 2-3
Code No.: 4.826
Weight: 0.013
No. of Cutting Edges: 3
Total Length: 70.000
Thread Length: 8.500
Groove Length: 21.000
Usable Length: 25.000
Norm 2: DIN 2184-1
Wrench Opening 1: 4.900
Neck Ø: 3.800
Core Hole Ø: 4.10
Shank Ø: 6.000
Nominal Dimension Thread: 10 – 32
External Ø: 4.880
Pitch Thread/Inch: 32.000
Reach Length: 50.000
Statistical Goods Number: 82074010
