Guhring UNF Spiral Taps HSS-E Gold Band NR 4 -48

Product Code: 5728 2,845

$105.05$95.50 Ex. GST

Product Code: 5728 2,845 SKU 5728 2,845 Category CUTTING TOOLS (HSS & Carbide)

Guhring UNF Spiral Taps HSS-E Gold Band NR 4 -48

Guhring UNF Spiral Taps HSS-E Gold Band NR 4 -48 - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Machine taps for UNF-threads 4 – 48 / 2B / ~DIN 374 / DIN 2184-1 / HSS-E / steam tempered / Type: N R40 / Form: C / blind hole / Cutting direction: right-hand

Additional information

Weight	0.0040 kg
Dimensions
barcode
Additional Information	Connection code machine side: straight shank Internal cooling: without Norm: ~DIN 374 Surface: steam tempered Discount group: 203 Type: 5728, N R40 Material: HSS-E Additional information: Internal threading Form: C Coloured ring: gold ring Threads: UNF Tolerance class thread: 2B Hole type: blind hole Groove: 40° right hand helix Chamfer lead length: 2-3 Code no.: 2.845 Weight: 0.004 No of cutting edges: 3 Total length: 56.000 Thread length: 6.000 Groove length: 14.000 Usable length: 18.000 Norm 2: DIN 2184-1 Wrench opening 1: 1.800 Neck Ø: 2.200 Core hole Ø: 2.40 Shank Ø: 2.200 Nominal dimension thread: 4 – 48 Pitch: 0.529 External Ø: 2.880 Pitch thread/inch: 48.000 Reach length: 37.000 Statistical goods number: 82074010

Brand

Guhring
