Guhring W 1/4 BSW Gun Nose Taps HSS-E Blue band Sirius Coated

Description

Machine taps for BSW-threads W1/4 / 3xD / ~DIN 371 / DIN 2184-1 / HSS-E / Sirius / Type: VA / Form: B / through hole / Cutting direction: right-hand

Weight	0.0230 kg
Dimensions
barcode	9046800063500
Additional Information	Connection code machine side: straight shank Internal cooling: without Norm: DIN 371 Surface: Sirius Discount group: 103 Type: 4680 Cutting direction: right-hand Type: VA Material: HSS-E Additional information: Internal threading Form: B Coloured ring: blue ring Threads: BSW Hole type: through hole Groove: straight-fluted cutting edges Chamfer lead length: 3.5-5.5 Code no.: 6.350 Weight: 0.023 No of cutting edges: 3 Total length: 80.000 Thread length: 16.000 Groove length: 26.000 Usable length: 30.000 Norm 2: DIN 2184-1 Wrench opening 1: 5.500 Core hole Ø: 5.10 Shank Ø: 7.000 Nominal dimension thread: W1/4 External Ø: 6.410 Pitch thread/inch: 20.000 Reach length: 59.000 Statistical goods number: 82074010
