Guhring W 1/4 BSW Spiral Taps HSS-E Yellow band

Product Code: 2847 6,350

$123.81$112.55 Ex. GST

Product Code: 2847 6,350 SKU 2847 6,350 Category CUTTING TOOLS (HSS & Carbide)

Guhring W 1/4 BSW Spiral Taps HSS-E Yellow band

Guhring W 1/4 BSW Spiral Taps HSS-E Yellow band - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Machine taps for BSW-threads W1/4 / 3xD / ~DIN 371 / DIN 2184-1 / HSS-E / steam tempered / Type: N R40 / Form: C / blind hole / Cutting direction: right-hand

Additional information

Weight	0.0180 kg
Dimensions
barcode
Additional Information	Connection Code Machine Side: straight shank Internal Cooling: without Norm: ~DIN 371 Surface: steam tempered Discount Group: 103 Type: 2847 Cutting Direction: right-hand Type: N R40 Material: HSS-E Additional Information: Internal threading Form: C Coloured Ring: yellow ring Threads: BSW Hole Type: blind hole Groove: 40° right hand helix Chamfer Lead Length: 2-3 Code No.: 6.350 Weight: 0.018 No. of Cutting Edges: 3 Total Length: 80.000 Thread Length: 13.000 Groove Length: 26.000 Usable Length: 30.000 Norm 2: DIN 2184-1 Wrench Opening 1: 5.500 Neck Ø: 4.900 Core Hole Ø: 5.10 Shank Ø: 7.000 Nominal Dimension Thread: W1/4 Pitch: 1.270 External Ø: 6.410 Pitch Thread/Inch: 20.000 Reach Length: 59.000 Statistical Goods Number: 82074010

Brand

Guhring
