Guhring W 3/16 BSW Gun Nose Taps HSS-E Yellow band

Product Code: 2892 4,762

$126.14$114.67 Ex. GST

Product Code: 2892 4,762 SKU 2892 4,762 Category CUTTING TOOLS (HSS & Carbide)

Guhring W 3/16 BSW Gun Nose Taps HSS-E Yellow band

Guhring W 3/16 BSW Gun Nose Taps HSS-E Yellow band - Image 2

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

Machine taps for BSW-threads W3/16 / 3xD / ~DIN 371 / DIN 2184-1 / HSS-E / steam tempered / Type: N / Form: B / through hole / Cutting direction: right-hand

Additional information

Weight	0.0110 kg
Dimensions
barcode
Additional Information	Connection code machine side: Straight shank Internal cooling: Without Norm: DIN 371 Surface: Steam tempered Discount group: 103 Type: 2892 Cutting direction: Right-hand Type: N Material: HSS-E Additional information: Internal threading Form: B Coloured ring: Yellow ring Threads: BSW Hole type: Through hole Groove: Straight-fluted cutting edges Chamfer lead length: 3.5-5.5 Code no.: 4.762 Weight: 0.011 No of cutting edges: 3 Total length: 70.000 Thread length: 14.000 Groove length: 21.000 Usable length: 25.000 Norm 2: DIN 2184-1 Wrench opening 1: 4.900 Neck Ø: 3.800 Core hole Ø: 3.60 Shank Ø: 6.000 Nominal dimension thread: W3/16 Pitch: 1.058 External Ø: 4.810 Pitch thread/inch: 24.000 Reach length: 50.000 Statistical goods number: 82074010

Brand

Guhring
