Guhring W 5/8 BSW Spiral Taps HSS-E Blue band TiALN coated

Description

Machine taps for BSW-threads W5/8 / 3xD / ~DIN 376 / DIN 2184-1 / HSS-E / TiAlN / Type: VA R45 / Form: C / blind hole / Cutting direction: right-hand

Weight	0.0910 kg
Dimensions
barcode	9046790158760
Additional Information	Connection code machine side: straight shank Internal cooling: without Norm: DIN 376 Surface: TiAlN Discount group: 103 Type: 4679 Cutting direction: right-hand Type: VA R45 Material: HSS-E Additional information: Internal threading Form: C Coloured ring: blue ring Threads: BSW Hole type: blind hole Groove: 45° right hand helix Chamfer lead length: 2-3 Code no.: 15.876 Weight: 0.091 No of cutting edges: 4 Total length: 110.000 Thread length: 24.000 Groove length: 49.000 Usable length: 53.000 Norm 2: DIN 2184-1 Wrench opening 1: 9.000 Core hole Ø: 13.50 Shank Ø: 12.000 Nominal dimension thread: W5/8 External Ø: 15.960 Pitch thread/inch: 11.000 Reach length: 58.000 Statistical goods number: 82074010
