ITM ARICAS GEAR HEAD FLOOR DRILL, 3MT, 240V 1PH

Description

Quality Taiwanese Precision Machine for drilling & tapping. # 3 Morse Taper Spindle. 1120W Single Phase Motor. Geared Head Tilts 90° right & left. Forward and Reverse Operation. Includes 3MT – J6 arbor with drawbar thread M12 x 1.75
No chuck supplied
Drilling Capacity Cast Iron: 40mm
Drilling Capacity Steel: 32mm
Spindle Taper: #3MT
Spindle Nose to Base: 620mm
Spindle to Colomn: 275mm
Diameter of Column: 110mm
Quill Diameter: 75mm
Quill Travel: 120mm
Swing: 550mm
Head Tilting: 90° Right & Left
Head Swivel: 360°
Spindle Speeds (240v) : 100, 220, 380, 760, 1240, 2500rpm
Spindle Speeds (415v) : 50, 100, 190, 380, 670, 1250rpm
Overall Height: 1075mm
Base Dimensions: 450 x 650mm
N.W. / G.W. : 220 / 245kg
Shipping Dimensions : 800 x 780 x 1120mm
