Swivel head enables from 0° to 60° mitre cuts. Dual mode operation. – Trigger switch with manual down feed for small quick cuts. – Control panel with fully adjustable hydraulic down feed & automatic shut-off at end of cut, for cutting larger material. Incorporated recirculating coolant system.
Brass chip brush to help prevent blade breakage.
Adjustable material stop for repetitive production.
Safety emergency stop switch.
12 months warranty.
Comes complete with stand & blade.
Optional blade tension gauge.
Made in Taiwan.
Motor: 1.5hp Three Phase (415V)
Blade Speed: 2 Speed 36 / 72mpm
Blade Size: 27mm x 0.9mm x 2455mm
Bed Height: 840mm
Weight: 216kg
90° Cutting Capacity:
Round: 220mm
Square: 215mm
Rectangle: 260 x 110mm
45° Right Cutting Capacity:
Round: 150mm
Square: 145mm
Rectangle: 155 x 110mm
60° Right Cutting Capacity:
Round: 90mm
Square: 85mm
Rectangle: 80 x 95mm
| Weight | 250.0000 kg |
|---|---|
| barcode | 9328042021830 |
