Swivel head enables from 0° to 60° mitre cuts.
Dual mode operation.
– Trigger switch with manual down feed for small quick cuts.
– Control panel with fully adjustable hydraulic down feed & automatic shut-off at end of cut, for cutting larger material.
Incorporated recirculating coolant system.
Adjustable material stop for repetitive production.
Safety emergency stop switch.
12 months warranty.
Comes complete with stand & blade.
Optional brass chip brush & blade tension gauge.
Made in Taiwan.
Motor: 1.0hp Single Phase (240V)
Blade Speed: Single Speed 80mpm
Blade Size: 19mm x 0.9mm x 2110mm
Bed Height: 895mm
Weight: 156kg
90° Cutting Capacity:
Round: 170mm
Square: 170mm
Rectangle: 210 x 95mm
45° Right Cutting Capacity:
Round: 120mm
Square: 110mm
60° Right Cutting Capacity:
Round: 70mm
Square: 60mm
| Weight | 170.0000 kg |
|---|---|
| barcode | 9328042011381 |
| Additional Information |
