KNIPEX 1000V SNIPE NOSE PLIERS 160MM

Product Code: 2506160SB

$99.51$90.46 Ex. GST

Product Code: 2506160SB SKU 2506160SB Category

Need Technical Advice?

Head over to our other technical website - millerstooling.com.au

Description

These tapered Snipe Nose Pliers combine several special qualities. On the one hand, they are suitable for fine, easy control and firm gripping of workpieces, as well as powerful cutting of cables and wires. The cutting edges are shaped for a more efficient pierced cut similar to a diagonal cutter. Additional induction hardening of the cutting edges (hardness approx. 61 HRC) lets the Knipex 25 06 160 cut cables, soft and medium-hard wire as well as hard wire. The vanadium electric steel precision tips of the pliers are flexible and torsion-resistant. Larger workpieces are held securely and smaller ones are gripped gently. Manual force is transferred efficiently, as the cutting edges are close to the joint. Cutting values of Ø2.5 mm on soft/medium-hard wire and Ø1.6 mm on hard wire speak for themselves. They are a welcome tool especially for electricians and fitters. Thanks to their insulated handles, the pliers are also suitable for work on live parts. Because they taper to the front, workpieces, wires and components are easily gripped and held.
Features:
Chrome finish effectively protects against corrosion.
Suitable for finer gripping and cutting work
Half-round, long, tapered jaws
Knurled gripping surfaces
With cutting edges for soft, medium-hard and hard wire
Cutting edges additionally induction-hardened, cutting edge hardness approx. 61 HRC
Vanadium electric steel, forged, multi stage oil-hardened

Additional information

Weight 0.1460 kg
Dimensions Length 16cm x Width cm x Depth cm
barcode
Additional Information

Pliers: chrome-plated
Head: chrome-plated
Handles: insulated with multi-component grips, VDE-tested
Dimensions: 160 x 53 x 17 mm
Standard: DIN ISO 5745 DIN EN 60900 IEC 60900
REACH compliant: does not contain SVHC
Cutting capacities medium hard wire (diameter): 2.5 mm
Cutting capacities hard wire (diameter): 1.6 mm
Jaw thickness (joint) (T1): 9.0 mm
Tips width (W4): 3.0 mm
Tips thickness (T2): 2.5 mm
Jaw length (L3): 50.0 mm
Head width (W3): 16.5 mm
Weight: 0.146kg

Brand

KNIPEX
